B-4 OPERATION
POWER WAVE 455
B-4
WELDING CAPABILITY
The POWER WAVE 455 is rated 400A@ 36V, 100%
duty cycle or 500A@40V 60% duty cycle. The
machine is capable of higher outputs at lower duty
cycles.
If the duty cycle is exceeded, a thermostat will shut off
the output until the machine cools to a reasonable
operating temperature.
LIMITATIONS
• The Power Wave is not recommended for process-
es other than those listed.
• The Power Wave can only be used with Power
Feed wire feeders. Other models of Lincoln feed-
ers, or any models of non-Lincoln wire feeders, can-
not be used.
COMPATIBLE LINCOLN EQUIPMENT
All Lincoln Power Feed ™ Wire Feeders.
POWER SOURCE OPERATION
DUTY CYCLE AND TIME PERIOD
The POWER WAVE 455 is rated at 400A@ 36V,
100% duty cycle or 500A@40V 60% duty cycle. The
duty cycle is based upon a ten minute period. A 60%
duty cycle represents 6 minutes of welding and 4 min-
utes of idling in a ten minute period.
CASE FRONT CONTROLS
All operator controls and adjustments are located on
the case front of the Power Wave.
1. POWER SWITCH: Controls input power to the
Power Wave.
2. STATUS LIGHT: A two color light that indicates
system errors. Normal operation is a steady green
light. Error conditions are indicated as follows:
NOTE: The Power Wave 455 status light will flash
green, and sometimes red and green, for up to one
minute when the Power Wave 455 is first turned on.
This is a normal situation as the machine goes
through a self test at power up.
3. HIGH TEMPERATURE LIGHT (thermal overload):
A yellow light that comes on when an over temper-
ature situation occurs. Output is disabled until the
machine cools down. When cool, the light goes
out and output is enabled.
4. 10 AMP WIRE FEEDER CIRCUIT BREAKER:
Protects 40 volt DC wire feeder power supply.
5. 5 AMP AUXILIARY POWER CIRCUIT BREAKER:
Protects 220 volt AC case front receptacle auxiliary
supply.
Light
Condition
Steady Green
Blinking
Green
A l t e r n a t i n g
Green and
Red
Steady Red
Blinking Red
Meaning
System OK. Power source communicating nor-
mally with wire feeder and its components.
Nothing connected to Wire Feeder
Receptacle.
Recoverable system fault.See
Troubleshooting Section.
Non-recoverable system fault. Must turn
power source off, find source of error, and
turn power back on to reset. See
Troubleshooting Section.
See Troubleshooting Section.
