A-8
INSTALLATION
POWER FEED 10 DUAL
A-8
MSB - Most Significant Bit or Byte. This is the bit in a binary number or DIP switch bank that is furthest to the left.
LSB - Least Significant Bit or Byte. This is the bit in a binary number or DIP switch bank that is furthest to the right.
S2 DIP Switch Bank on Control Box Motherboard (For software version S24456)
Switch
Off
On
1
Network Group ID, MSB (Assigns Control Box to a specific group) (Off is factory setting)
2
Network Group ID, LSB (Assigns Control Box to a specific group ) (Off is factory setting)
3
4-Step Domestic Configuration
4-Step European Configuration
4
Power Feed 10 Dual / Dual
Power Feed 11
5
Procedure Change with Trigger “OFF”
Procedure Change with Trigger “ON”
6
Set lower limits
7
Set upper limits
8
Must be on for all units (Permits selection of extended modes)
Note: the factory shipped settings for the S2 switches are as follows:
PF-10 (and Dual) Domestic - switches 1-7 “OFF”, 8 “ON”
PF-10 (and Dual) European - switches 1,2,4-7 “OFF”, 3,8 “ON”
PF-11 Domestic - switches 1-3,5-7 “OFF”, 4,8 “ON”
PF-11 European - switches 1,2,5-7 “OFF”, 3,4,8 “ON”
DIP SWITCH 6
DIP SWITCH 7
DIP SWITCH 8
Acceleration 1 (slow)
Off
Off
On
Acceleration 2
Off
On
Off
Acceleration 3
Off
On
On
Acceleration 4
On
Off
Off
Acceleration 5 (fast ) (factory setting)
Off
Off
Off
Setting Wire Drive Acceleration Rate Using
(All software versions)
DIP Switch S1 on the Control Box Motherboard
