Page 14
A-7
INSTALLATION
MAGNUM COOLER 10-I & 20-I
A-7
A
POWER SOURCE HEIGHT
16.44" (417.6mm)
POWER SOURCE HEIGHT
21.50" (546.1mm)
B
E
POWER SOURCE HEIGHT
27.50" (698.5mm)
POWER SOURCE HEIGHT
21.50" (546.1mm)
D
POWER SOURCE HEIGHT
16.44" (417.6mm)
C
Cooler 10-I Mounting Scheme
Cooler 20-I Mounting Scheme
FIGURE 3c
Undercarriage Mounting Bracket Layout
