A-2 INSTALLATION
MAGNUM ® 400 DUAL PROCEDURE GUNS
A-2
Description
Gun Contact Tips Gas
Product Cable Wire Size Standard Diffuser Gas Cable Gun Tube
Number Length (m) in. (mm) Duty Assembly Nozzle Insulator Liner 60°
15 ft .035 (0.9) KP14-35
K574-1 (4.5) .045 (1.2) -45 KP54A KP24A-62 KP34A KP44-3545-15 KP1928-1
15 ft .052 (1.3) KP14-52
K574-2 (4.5) 1/16 (1.6) -116 KP54A KP24A-62 KP34A KP44-116-15 KP1928-1
15 ft 1/16 (1.6) KP14-116
K574-3 (4.5) 5/64 (2.0) -564 KP54A KP24A-62 KP34A KP44-564-15 KP1928-1
25 ft .035 (0.9) KP14-35
K574-4 (7.6) .045 (1.2) -45 KP54A KP24A-62 KP34A KP44-3545-25 KP1928-1
25 ft .052 (1.3) KP14-52
K574-5 (7.6) 1/16 (1.6) -116 KP54A KP24A-62 KP34A KP44-116-25 KP1928-1
25 ft 1/16 (1.6) KP14-116
K574-6 (7.6) 5/64 (2.0) -564 KP54A KP24A-62 KP34A KP44-564-25 KP1928-1
10 ft. .035 (0.9) KP14-35
K1722-1 (3.0) .045 (1.2) -45 KP54A KP24A-62 KP34A KP44-3545-15 KP1928-1
15 ft. .035 (0.9) KP14-35
K1722-2 (4.5) .045 (1.2) -45 KP54A KP24A-62 KP34A KP44-3545-15 KP1928-1
25 ft. .035 (0.9) KP14-35
K1722-3 (7.6) .045 (1.2) -45 KP54A KP24A-62 KP34A KP44-3545-25 KP1928-1
MAGNUM ® 400 Dual Procedure
400 AMPS at 60% DUTY CYCLE WITH CO
2
GAS
400 AMPS at 50% DUTY CYCLE WITH MIXED GAS
