C-1
EXPENDABLE REPLACEMENT PARTS
C-1
EXPENDABLE REPLACEMENT PARTS FOR MAGNUM® 450WC GUN & CABLE ASSEMBLIES
EXPENDABLE REPLACEMENT PARTS FOR MAGNUM® 650WC GUN & CABLE ASSEMBLIES
Part Number
English
Metric
Description
(Color Code)
Size (In.)
Size (mm)
CABLE LINER
For Cables 15' (4.5 m)
KP44-3545-15
.035-.045"
0.9-1.2 mm
and less (Steel Wire)
KP44-116-15
.052-1/16"
1.3-1.6 mm
KP44-564-15
1/16-5/64
1.6-2.0 mm
For Cables 15' (4.5 m)
KP1958-2 (Black)
.030-.035"
0.9-1.2 mm
and less (Aluminum Wire)
KP1958-4 (Red)
1/16"
1.6 mm
KP1958-6 (Blue)
.035-.045
0.9-1.2 mm
For Cables 10' (3.0 m)
KP1958-1 (Black)
.035-3/64"
0.9-1.2 mm
and less (Aluminum Wire)
KP1958-3 (Red)
1/16"
1.6 mm
KP1958-5 (Blue)
.035-3/64”
0.9-1.2 mm
CONTACT TIPS
KP2067-1B2
.035"
0 9 mm
KP2067-1B2
.035A"
0.9A mm
KP2067-3B1
.040"
1.0 mm
KP2067-3B1
.040A"
1.0A mm
KP2067-5B1
.045"
1.2 mm
KP2067-9B1
3/64A"
1.2A mm
KP2067-6B1
.052"
1.3 mm
KP2067-7B1
1/16"
1.6 mm
KP2067-7B1
1/16A”
1.6A mm
KP2067-10B1
5/64”
2.0 mm
GAS DIFFUSER
KP2059-1
INSULATOR
KP2060-1
GAS NOZZLE
Flush
KP1957-1
0.39”
10 mm
Flush
KP1957-2
0.51”
13 mm
Flush
KP1957-3
0.59”
15 mm
.12” (3 mm) Recess
KP1957-4
0.59”
15 mm
.12” (3 mm) Recess
KP1957-5
0.76”
19.2 mm
Spot
KP1957-6
0.76”
19.2 mm
GUN TUBE ASSEMBLY
REPLACEABLE PARTS
Gun Tube Insulation Disk
S22333-7A
Nozzle Holder
S24298-7B*
Set Screw
S24298-7C
Ceramic Insulator
S22333-7D*
Insulation Ring
S24298-7G
*Joint Compound
T12837
* Joint compound is required for assembly of these parts.
Part Number
English
Metric
Description
(Color Code)
Size (In.)
Size (mm)
CABLE LINER
For Cables 15' (4.5 m)
M19265-1(yellow)
5/64-3/32"
2.0-2.4 mm
and less (Steel Wire)
CONTACT TIP
KP2067-10B1
5/64”
2.0 mm
GAS DIFFUSER
KP2058-2
INSULATOR
S22031-2
GAS NOZZLE
.12” (3 mm) Recess
M19127-1
0.59”
15 mm
.12” (3 mm) Recess
M19127-2
0.67”
17 mm
.12” (3 mm) Recess
M19127-3
0.87”
22.2 mm
GUN TUBE ASSEMBLY
REPLACEABLE PARTS
Gun Tube Insulation Disk
S24333-7A
Nozzle Holder
S24333-7B*
Set Screw
S24298-7C
Ceramic Insulator
S24333-7D*
Insulation Ring
S24333-7G
*Joint Compound
T12837
