MODEL XMC90 OWNER’S MANUAL
VERSION V 0.0 Page 8 of 20
2.8 Volume Control and Select Button
2.8.1 Volume Control
This integral scroll wheel/volume control and select button is also used to adjust the speaker volume (when not scrolling
through menu items for selection or adjustment) in the XM/FM/AM/AUX/iPod modes within the range of 0~30.
2.8.2 Select Button
Momentarily press and release the scroll wheel to activate the scrolling function. In XM/iPod mode, press the scroll wheel
twice; a beep will be heard. Then rotate the scroll wheel to browse the XM/iPod menu.
2.9 MODE Button
This button enables selection of one of five play modes in a sequential wrap-around format (XM/FM/AM/AUX/iPod).
2.10 Infrared (IR) Receiver Window
This window detects the IR signal from the remote control to select operating modes and feature functions.
2.11 LCD Display
Displays operating modes, menus and other related information on the LCD screen.
2.12 SLEEP Button
Press this button to set a sleep time of 30, 60 or 90 minutes; use the scroll wheel to scroll through and highlight the
available sleep times, then press select. The radio will turn off automatically when the sleep time has expired.
Rotate the scroll wheel to adjust
the output volume in any mode
Press this button in any
play mode; the current
mode is highlighted
Use the scroll wheel to highlight
another selection; press the
select button to select the new
Press the
sleep button in
any play mode
Highlight the desired
sleep time, then press
select
