C-1 ACCESSORIES C-1
OPTIONS / ACCESSORIES
CABLE PLUGS
K852-70 - Cable Plug Kit for 1/0-2/0 cable. Attaches
to welding cable to provide quick disconnect from
machine.
K852-95 - Cable Plug Kit for 2.0-3/0 cable.
NOTE: Two K852-70 plugs are included with the
V250-S.
REMOTE CONTROLS
K857 - Remote Output Control for stick welding.
K963 - Hand Amptrol tm for TIG welding. When the
V250-S ’ s Output Control is in the “ Remote ” position,
the hand Amptrol energizes the output and controls
the output remotely. The Hand Amptrol connects
directly to the 6 pin Amphenol.
Note: When used with the V250-S, the grounding
strap on the connector end of K963 must be discon-
nected to avoid electrical noise problems. Details are
listed under REMOTE CONTROL RECEPTACLE in
INSTALLATION section in this manual.
K870 - Foot Amptrol tm for TIG welding. When the
V250-S ’ s Output Control is in the “ REMOTE ” position,
the foot Amptrol energizes the output and controls the
output remotely. The Hand Amptrol connects directly
to the 6 pin Amphenol.
K814 - Arc Start Switch. Energizes the output for TIG
welding if remote output control of the amperage is
not desired. When using the Arc Start Switch set the
Output Control to the
“ LOCAL ” position.
INVERTEC V250-S
