– 9 –
TECHNICAL SPECIFICATIONS: IDEALARC AC/DC 250
Model AC/DC 250 AC/DC 250
Type K1053 K1054
AC Input Frequency 60 50
Output Rating NEMA CLASS II (60) IEC 974
AC DC AC DC
Amperes 300 250 250 250
Volts 32 30 30 30
Duty Cycle 20 30 30 30
Current Range 35-300 40-250 35-250 40-250
Max. O.C.V. 72 70 72 70
Input Power
Standard Voltages 208/230/460 220/380/440
230/460/575 380/415/500
Rated Input Current
(230V 60Hz, 220V 50Hz)
With Condensers 68 68
Without Condensers 86 86
Idle Input Current (230V)
With Condensers 23 23
Without Condensers 6.2 6.2
Power Factor (200 Amp Load)
With Condensers 83.3 83.3
Without Condensers 69.0 69.0
INPUT - OUTPUT RATINGS
HEIGHT WIDTH DEPTH WEIGHT
27.00 in. 19.00 in. 21.50 in. 350 lbs.
159 kg
686 mm 483 mm 546 mm
PHYSICAL DIMENSIONS
