Technical specifications – Johnson Level & Tool Mfg. 40-6584 User Manual
Page 24

24
©2012 Johnson Level & Tool
9. Technical Specifications
Laser Wavelength
635nm±10nm
Laser Classification
Class IIIa
Maximum Power Output
≤
5mW
Accuracy
±1/16"/100 ft. (±1.5mm/30m)
Interior Range
Up to 200 ft. (60m) diameter depeding on
light conditions
Exterior Range
Up to 2000 ft. (600m) diameter
Remote Range
Up to 200 ft. (60m) diameter
Auto-Leveling Range
±8°
Grade Setting
X Axis -10% – +10%
Y Axis -1% – +25%
|X| + |Y| = 20%
Scan Speed
600 and 1100 rpm
Power Supply
Li-ion Rechargeable Battery Pack or
adapter (included); 3 “D” Alkaline
batteries (not included)
Battery Life
Approx. 40 hours with Li-ion Rechargeable
Battery Pack (included)
Dimensions
9.252" x 7.086" x 9.763"
(235 x 180 x 248mm)
Weight
7.275 lbs. (3.3Kg)
Working Temperature
14°F to 113°F (-10°C to 45°C)
Center Screw Thread
5/8" – 11
IP Protection Class
66
