6. Operating Instructions

IMPORTANT: It is the responsibility of the user to verify the
calibration of the instrument before each use.

Battery Installation
Note: Always check to be sure that the compensator lock/unlock switch
is in the locked position before removing and replacing batteries.

1. As shown in figure, open the battery cover.

2. Put three “AA” alkaline batteries into the

battery compartment noting polarity

3. Close the battery cover.

7. Using the Product

Place the laser on a relatively smooth, flat and

level surface.

Note: Product must be within ±4º of level for
self-leveling feature to function properly. Greater
than 4º will result in an alarm condition (flashing
laser and intermittent beeping sound).

Place the laser on a tripod using the multi-functional

base.
