Keypad Operating Instructions

Power button
Press the power button to turn on and off the laser. The laser
will electronically self level and display the last grade entered.

LCD backlight and LED button
Power on the laser and press the LCD/LED button . The top
green LED will turn on. The line-axis pivot marker and LED identifies
the pivot point for the pipe lasers line system. The LED also allows
you to align a transit over the top of the pipe laser.

Left and Right line control buttons
With the laser powered on, press the left line control button to move
the laser beam to the left and press the right line control button to
move the laser beam to the right. The speed of the line movement
increases as the line control button is held.

When the laser dot is moving, the LCD display will show the relevant
laser dot position.
A *---- symbol flashing means the laser dot is as far left as it can go.
A -*--- symbol means the laser dot is on the left
A --*-- symbol means the laser dot is centered
A ---*- symbol means the laser dot is on the right
A ----* symbol flashing means the laser dot is as far to the right

as it can go.
