©2012 Johnson Level & Tool - Rev. 1 11
Battery symbol
With the laser powered on, check the battery capacity symbol to note the power status on
the LCD display.
Full battery, no need to charge
Low battery, laser can be used
No power, battery pack needs to be recharged or new alkaline batteries must be
installed
Remote function
Included with the pipe laser is a remote control. The keypad function of the remote
control is the same as the pipe laser, except the power button .
• Press the power button on the remote when pipe laser is turned on and the pipe laser
will enter the sleep mode. The pipe laser saves the current data and powers down.
• The laser beam will be off in the sleep mode and the top LED will flash slowly. Press
the power button on the remote again and it will power up the laser. If the laser is in
the sleep mode for more than 30 minutes, it will power off automatically.
• Remote range: front (laser output window end) 165’ or 50m, back (handle end) 35’
or 10m.
