©2007 Johnson Level & Tool 7
6. Operating Instructions
IMPORTANT: It is the responsibility of the user to verify the
calibration of the instrument before each use.
Battery Installation
Note: Always check to be sure that the on/off switch is in the off
position before removing and replacing batteries.
Battery kit: • “C” alkaline battery box
• Rechargeable battery-pack (40-6530 only)
1. Loosen the set-bolt and take the battery box apart from the unit,
as shown in fig. a.
2. Put in four “C” batteries (included with 40-6525 only) according to
the polarity illustrated in the battery box, and snap the battery box
back into place, as shown in fig. b and c.
3. If using the rechargeable battery-pack, (40-6530 only) fix the
battery-box onto the unit directly, and tighten the bolt (fig. c).
Bolt
Alkaline Battery
Box
