9. Technical Specifications
Laser Wavelength 635nm±10nm
Laser Classification Class IIIa
Maximum Power Output
≤5mW
Accuracy ±1/16"/100 ft. (±1.5mm/30m)
Exterior Range Up to 2000 ft. (600m) diameter
Remote Range Up to 100 ft. (30m) diameter with remote
Auto-Leveling Range ±5°
Slope ±5º
Power Supply Rechargeable battery pack, or 6V adapter
(included) or 6 “AA” battery holder
(batteries not included).
Battery Life Approx. 17 hours with rechargeable battery
pack, 8 hours with 3 “AA” alkaline batteries
and 17 hours with 6 “AA” batteries
Dimensions 5.512" x 5.512" x 7.480"
(140 x 140 x 190mm)
Weight 3.968 lbs. (1.8Kg)
Working Temperature 14°F to 113°F (-10°C to 45°C)
Center Screw Thread 5/8" – 11
Rotation Speed 800 rpm
IP Protection Class 66
