axis. The re-calibration LED turns off and the value of the
re-calibration will be stored. The laser has now exited
re-calibration mode.

Note: In order to make the saved calibration effective, you must

power off the instrument after calibration, and then power it
on again. Y-axis accuracy check is a necessity after the X-axis
calibration, and X-axis accuracy check is also a necessity after
the Y-axis calibration. Laser re-calibration will not be finished
until both X-axis and Y-axis accuracy meet the specifications.

Detector Usage
1. Product Description
A laser detector is an indispensable accessory when using this rotary
laser level. The main function of the detector is to locate the position
of laser signals transmitted by rotary lasers. This detection quickly
and precisely provides the user with the horizontal reference. This
product features a high level of sensitivity, a double-faced display, low
power consumption, reliability and easy use.

2. Technical Specifications

Detecting accuracy

Fine ±0.039" (±1mm)
Coarse ±0.098" (+2.5mm) when range is < 492 ft. (150m)

±0.138" (+3.5mm) when range is > 492 ft. (150m)

Turn-off time

6 minutes ±1 minute

Power

1 9V battery

Sound indicator

slow short sounds, rapid short sounds
and a continuous sound

LED indicator

up, level, down

Dimensions

5.906" x 2.992" x 1.142" (150 x 76 x 29mm)

Weight

0.485 lb. (220g)

Others

Rain and dust resistant
