©2012 Johnson Level & Tool 35
Optical Plummet
Imaging
Erect
Magnification 3x
Focusing range 0.5m
Field Angle 5°
Display
Type
LCD with Double Side
Data Input and Output
Joint (one)
RS232
Power
Battery
5 “AA” Alkaline Batteries or
Rechargeable NiMH Battery Pack
Operating Voltage 6V DC
Operating Time 16 hours
Working Environment
Temperature Range
-4°F to +104°F (-20°C to +40°C)
Size and Weight
Outside Dimension
6.29” x 5.90” x 12.99”
(160x150x330mm)
Weight 10.14 lbs (4.6kg)
