Battery Replacement
Remove Battery Box
Replace Alkaline Batteries
• Push down the battery cover tab and pull the battery cover away
from the battery box.
• Take the old batteries out and put the new batteries in paying
attention to the “+” and “-” pole.
• Snap the battery cover back into place.
Placing the Battery Box on the Instrument
Place the projection on the bottom
of the battery box into the slot on
the instrument. Push the top of
the battery box until it clicks into
place.
©2012 Johnson Level & Tool 13
Battery Box Button
Push down to remove
the battery box
Hook
Battery Cover Battery Cover
