Note: All operation buttons will be non-responsive, except buttons 1,
2, & 7. Push the MEAS button again so light turns off to utilize
buttons 3, 4 and 5 below.

Begin measuring only after the link light of the Remote
Control/Receiver and Sensor/Slaver are illuminated. If there is a
delay in the illumination or the units are not connected, power down
and then power up again.

3. Resolution Button (SEN/DEG)
Pushing this button will switch resolutions
a. 0.002º - 0.01º - 0.1º - 1º - 0.002º
b. Degree - Minute - Second

4. Function Button (mm, m; in/ft; CHN)
Pushing this button will switch functions
a. Percentage of Slope (%)
b. mm / M
c. in / ft
d. Channel Select (A-B-A)

5. Absolute, Relative and Degree Button (ABS/REL, WARN)
a. Absolute and Relative: switch between absolute and

relative value

b. Degree Alert Set-Up

1. When degrees stop to X1 and Y1, press MEAS to

pause measure.

2. Press and hold this button until 3 beeps are heard to set

alarm mode for 1 degree, LCD will display “1”.
