48
SECTION X
BURNER MANUAL RESET HI-LIMIT INSTRUCTIONS
IMPORTANT
FOR MECHANICAL METER, TIMER OR PHASE 5 WITHOUT HEAT FAULT
(GAS MODELS ONLY)
This dryer was manufactured with a burner manual reset hi-limit thermostat. If this burner manual reset
hi-limit thermostat is open prior to the start of the drying cycle, or during the cycle, the dryer will not recognize
the open state of the burner hi-limit thermostat and will start or continue through the drying cycle with no heat.
Manual reset hi-limit thermostat must be reset manually.
This hi-temperature condition may be caused due to a restricted exhaust, poor airflow, or improper burner oven
operation.
The location of the manual reset hi-limit switch is on the right side of the burner box.
