6
SECTION II
SPECIFICATIONS
A. SPECIFICATIONS
GAS
MAXIMUM CAPACITY (DRY WEIGHT) 30 lbs 13.6 kg
BASKET (TUMBLER) DIAMETER 30” 76.2 cm
BASKET (TUMBLER) DEPTH 30” 76.2 cm
BASKET (TUMBLER) MOTOR 1/2 hp* 0.373 kW
DOOR OPENING (DIAMETER) 21-1/2” 54.61 cm
BASKET (TUMBLER) VOLUME 12.27 cu ft 0.347 cu m
DRYERS PER 20’/40’ CONTAINER 12/28
DRYERS PER 45’/48’ TRUCK 32/36
VOLTAGE AVAILABLE 120-460v 1ø 50/60 Hz
APPROX. WEIGHT (UNCRATED) 535 lbs 242.7 kg
APPROX. WEIGHT (CRATED) 585 lbs 265.4 kg
HEAT INPUT 90,000 Btu/hr 22,680 kcal/hr
AIRFLOW 600 cfm 17 cmm
INLET PIPE CONNECTION 1/2” M.N.P.T.**
Shaded areas are stated in metric equivalents 07/21/03
* Reversing dryer available with 3-phase (3ø) 1/2 hp (0.373 kW) motors standard.
** Size of piping to dryer varies with installation conditions. Contact factory for assistance.
NOTE: Manufacturer reserves the right to make changes in specifications at any time without notice or
obligation.
