Elitegroup H81H3-M3S/TPM (V1.0) User Manual
Page 3
iii
H81H3-M3S USER MANUAL
Chapter 2
7
Installing the Motherboard 7
Safety Precautions.............................................................................7
Installing the Motherboard in a Chassis......................................7
Checking Jumper Settings.................................................................8
Installing Hardware..................................................................9
Installing the Processor.............................................................9
Installing the CPU Cooler.........................................................11
Installing Memory Modules....................................................12
Installing Add-on Cards...........................................................13
Connecting Optional Devices..................................................15
Installing a SATA Hard Drive...................................................20
Connecting Case Components.......................................................21
Front Panel Header.................................................................23
TABLE OF CONTENTS
Preface
i
Chapter 1
1
Introducing the Motherboard
1
Introduction...................................................................................1
Pakage Contents............................................................................1
Specifications................................................................................2
Motherboard Components..........................................................4
I/O Ports..............................................................................................6
Chapter 3
25
Using BIOS
25
About the Setup Utility................................................................25
The Standard Configuration....................................................25
Entering the Setup Utility........................................................25
Resetting the Default CMOS Values.....................................26
Using BIOS........................................................................................26
BIOS Navigation Key
s..
............................................................27
Main Menu.............................................................................28
Advanced Menu......................................................................29
Chipset Menu..........................................................................44
M.I.B III(MB Intelligent Bios III) Menu....................................51
Boot Menu...............................................................................59
Security Menu..........................................................................60
Exit Menu................................................................................61
