Chapter 3
B85H3-M3 USER MANUAL
60
Over Voltage Configuration
Scroll to this item to view the following screen:
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
DIMM Voltage 1.500V (Auto)
F4: Save & Exit
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
The selection of Memory
Profiles which impacts
memory sizing behavior. DIMM Voltage 1.500V Auto
ChoWriteVref 0.728V Auto
Ch1WriteVref 0.768V Auto
ChVrefCA 0.768V Auto
ChReadVref 0.768V Auto
CPU Adaptive Voltage Target (mV) 0
CPU Voltage Mode Adaptive
CPU Voltage Offset (mV) 0
Offset Prefix +
RING/Cahe Adaptive Voltage Target 0
RING/Cahe Voltage Mode Adaptive
RING/Cahe Voltage Offset (mV) 0
Offset Prefix +
SVID Control Enable Enabled
SVID Override Voltage Target (mV) 0
FIVR Faults Enable Enabled
FIVR Efficiency Enable Enabled
GT Adaptive Voltage Target (mV) 0
GT Voltage Mode Adaptive
GT Voltage Offset (mV) 0
Offset Prefix +
UNCORE Voltage Offset (mV) 0
Offset Prefix +
IOA Voltage Offset (mV) 0
Offset Prefix +
IOD Voltage Offset (mV) 0
Offset Prefix +
This item allows you to adjust DIMM Voltage.
ChoWriteVref/Ch1WriteVref 0.728V/0.768V (Auto)
These items allow you to adjust Ch0WriteVref/Ch1WriteVref 0-108. Default = 54, 1
Step = 4 mV.
ChVrefCA 0.768V (Auto)
This item allows you to adjust ChVrefCA 0-108. Default = 54, 1 Step = 4 mV.
ChReadVref 0.768V (Auto)
This item allows you to adjust ChReadVref 0-108. Default = 54, 1 Step = 4 mV.
CPU/RING/Cahe Adaptive Voltage Target (mV) (0)
These items show CPU/RING/Cache Adaptive Override Voltage Target, 0mV ~ 2000mV.
CPU/RING/Cahe Voltage Mode (Adaptive)
These items allow you to set CPU/RING/Cache Voltage Mode.
