B85H3-M6 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Supports the LGA1150 socket for 4
th
Generation
Core
TM
Family Processors
2. Buzzer Buzzer
3. CPU_FAN CPU cooling fan connector
4. DDR3_1~4 240-Pin DDR3 long DIMM slots
(Channel A: DIMM1~2 Channel B: DIMM3~4)
5. CASE Case open header
6. LPT Onboard parallel port header
7. ATX_POWER Standard 24-pin ATX power connector
8. COM2 Onboard serial port header
9. SATA3_1~4 Serial ATA 6.0Gb/s connectors
10. SATA 5 Serial ATA 3.0Gb/s connector
11. USB3F Front panel USB 3.0 connector
12. F_PANEL Front panel switch/LED header
13. CLR_CMOS Clear CMOS header with jumper
14. F_USB1~2 Front panel USB 2.0 headers
15. F_USB3 Front panel USB 2.0 header
16. F_AUDIO Front panel audio header
17. PCIEX16_S PCI Express x16 slot (runs at X4 mode)
18. PCI 32-bit add-on card slot
19. PCIE PCI Express x1 slot
20. PCIEX16 PCI Express x16 slot
21. SYS_FAN System cooling fan connector
22. COM1 Onboard serial port header
23. ATX_12V Auxiliary 4-pin power connector
