7
English
Step 1. Ins of the CPU and CPU Cooler:
Hardware Guide
Ins Steps
Step 2. of Memory Modules:
2-1. Unfasten the latches on each side
of the DIMM slots.
Step 3. Ins of Motherboard:
3-1. Replace the back I/O plate of the
case with the I/O shield provided in
motherboard’s package.
2-2. Firmly press the DIMM down un l it
seats correctly. Make sure the slot
latches are levered upwards and latch
on the edge of the DIMM.
3-2. Place the motherboard within the
case by
it into the I/O plate.
Secure the motherboard to the case
with screws.
Step 4. of an Expansion card:
Remove the metal located on the slot and then insert the expansion card into the
slot. Press the card Įrmly to make sure it is fully inserted into its slot. And then
return the screw back to its
.
Locate the CPU cut edge (the corner with
insert the CPU correctly, then press the
1-2. Apply thermal grease on top of the
CPU. Put the CPU Fan down on the
module and Ňip the levers
over the heat sink in place.
