A990fxm-a user manual, Chapter 1, Table of motherboard components – Elitegroup A990FXM-A (V1.1) User Manual
Page 9

5
A990FXM-A USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL
COMPONENTS
1. CPU Socket
AMD Phenom
TM
and later desktop processors (socket AM3+)
2. CPU_FAN
CPU cooling fan connector
3. DDR3_1/2/3/4
240-pin DDR3 SDRAM slots
4. BZ
Buzzer
5. ATX_POWER
Standard 24-pin ATX power connector
6. PWR_FAN
Power cooling fan connector
7. SATA1~6
Serial ATA 6Gb/s connectors
8. PANEL
Front panel switch/LED header
13. F_USB2
Front panel USB 2.0 header
9. CLR_CMOS
Clear CMOS jumper
10. F_USB1~2
Front panel USB 2.0 headers(F_USB1 with EZ Charge function)
11. CASE
Case open header
12. SYS_FAN
System cooling fan connector
13. SPDIFO
SPDIF out header
14. F_AUDIO
Front panel audio header
15. PCI
32-bit add-on card slot
16. PCIEX16_S
PCI Express slot for graphics interface
17. PCIE1~2
PCI Express x1 slots
18. PCIEX16_1~2
PCI Express slots for graphics interface
19. ATX12V
8-pin +12V power connector
