Ref # Part #
Description
Qty.
1 ...... 57482 ............ Nut, Valve Needle Housing 9/16-18, width across flats: 0.75, thickness: 0.12 .... 2
2 ...... 54401 ............ Locknut.............................................................................................................. 2
3 ...... 58079 ............ Knob .................................................................................................................. 2
4 ...... 57889 ............ Knob, Insert ....................................................................................................... 2
5 ...... 57256 ............ Gear, Spur 40 Teeth ........................................................................................... 2
6 ...... 59233 ............ Gear, Spur 18-tooth ........................................................................................... 2
7 ...... 55896 ............ Valve Seat .......................................................................................................... 4
8 ...... 59387 ............ Valve Seat, Stem ................................................................................................ 4
9 ...... 59045 ............ Valve, Needle Seat ............................................................................................. 4
10 .... 54540 ............ Housing, Valve Needle ....................................................................................... 2
11 .... 59551 ............ Valve Needle ...................................................................................................... 2
12 .... 57906 ............ Bushing, End ..................................................................................................... 1
13 .... 59378 ............ Cap, End ........................................................................................................... 1
14 .... 59495 ............ Shaft .................................................................................................................. 1
15 .... 59241 ............ Piston ................................................................................................................ 1
16 .... 55714 ............ Body, Dual Valve ................................................................................................ 1
17 .... 57580 ............ Knob .................................................................................................................. 1
18 .... 55533 ............ Valve Needle ...................................................................................................... 2
19 .... 55159 ............ Housing, Valve Needle ....................................................................................... 2
20 .... 56784 ............ Locknut, 9/16-18UNF-3A, SST .......................................................................... 1
21 .... 59845 ............ Plug, Expansion, 0.1562 + 0.0000/-0.0012 hole diameter ............................... 14
23 .... 59383 ............ Setscrew, 6-32NC x 1/8 SST ............................................................................. 4
24 .... 58342 ............ Screw, Cap Hex Socket Head, #2-56UNC-3A purchase per mil spec 16995-2 .. 6
25 .... 59322 ............ Setscrew, 6-32NC x 1/4 SST ............................................................................. 6
26 .... 59326 ............ Setscrew, 2-56NC x 1/8, alloy steel ................................................................... 4
27 .... 55554 ............ O-ring, AS568A dash no. 010, Buna-N (Nitrile) 70 durometer color black ........... 5
28 .... 55536 ............ O-ring, AS568A dash no. 002, Buna-N (Nitrile) 70 durometer color black ........... 4
29 .... 55573 ............ Shaft O-ring, AS568A Dash No 117, Buna-N (Nitrile) 70 durometer color black ...... 1
30 .... 60633 ............ Retainer, Packing Backup, single turn tetrafluoroethylene ................................... 4
31 .... 55570 ............ Washer, Backing 0.04 thick, tetrafluoroethylene resin ......................................... 4
32 .... 55577 ............ O-ring, AS568A dash No 111, Buna-N (Nitrile) 70 durometer color black ........... 1
33 .... 59245 ............ Washer, #8 Screw Size 0.187, ID x .440 OD x .040 thick nylon .......................... 2
34 .... 60202 ............ Setscrew, hex .................................................................................................... 2
35 .... 60837 ............ Screw, MACH Pan Head #10- 32NF x 1/2 phillips head 300 series stainless steel .. 2
36 .... 58976 ............ Screw, Self Sealing, 8-32 x 5/8 modified to print ................................................ 1
38 .... 53308 ............ Label Roll, 1.25 x 1.25, polytrans 3000 void, 3" Core, 8" OD ............................. 1
41 .... 59878 ............ Spacer, 0.005 thick mylar ................................................................................... 2
42 .... 59880 ............ Spacer, 0.007 thick mylar ................................................................................... 2
ORION-2C Pneumatic Pressure Controller
Bill of Material
