6
INSTALLATION GUIDE FOR THE BURCAM’S Fan Air
MODEL F80210
Put the fan casing on top of the suction tunnel.
Then, from the outside, slide in the evacuation pipe
and adapt it to the elbow of the fan casing. This will
show you where to cut the length of pipe to finalize
the installation of the outside vent.
It may be necessary to make several cuts to the
pipe end to secure the outside vent.
Apply caulking between the outside vent and the
outside wall to act as a weather seal.
STEP 8
STEP 9
STEP 10
STEP 11
8
10
11
