SAFETY INSTRUCTIONS:
This fine pump that you have just purchased is designed from the latest in material and
workmanship. Before installation and operation, we recommend the following procedures:
CHECK WITH YOUR LOCAL ELECTRICAL AND PLUMBING CODES TO ENSURE YOU
COMPLY WITH THE REGULATIONS. THESE CODES HAVE BEEN DESIGNED WITH YOUR
SAFETY IN MIND. BE SURE YOU COMPLY WITH THEM.
WE RECOMMEND THAT A SEPARATE CIRCUIT BE LEAD FROM THE HOME ELECTRICAL
DISTRIBUTION PANEL PROPERLY PROTECTED WITH A FUSE OR A CIRCUIT BREAKER.
THE MOTOR HAVE TO BE SECURELY PLUGGED INTO A PROPER ‘GFCI’ ELECTRICAL
OUTLET. CONSULT A LICENSED ELECTRICIAN FOR ALL WIRING.
THE GROUND TERMINAL ON THE THREE PRONG PLUGS SHOULD NEVER BE REMOVED.
THEY ARE SUPPLIED AND DESIGNED FOR YOUR PROTECTION.
NEVER MAKE ADJUSTMENTS TO ANY ELECTRICAL APPLIANCE OR PRODUCT WITH
THE POWER CONNECTED. DO NOT ONLY UNSCREW THE FUSE OR TRIP THE BREAKER,
REMOVE THE POWER PLUG FROM THE RECEPTACLE.
MONTHLY MANDATORY CHECK-UP :
1. Inspect the pump and the sump for any obvious condition that necessitates cleaning, correction, adjustement or repair.
2. Clear the sump and the surroundings of any paper, leaves or other debris that might clog the input openings. Remove anything that
might float into the suction area.
3. Assure that the pump is secure and vertical for proper operation.
4. Assure that there is adequate clearance from any combustible materials or structure. Stored materials must be kept away from the
pump. Shelves or cabinet structures must not be in close proximity over the pump.
5. Test the ‘GFCI’ outlet by pressing its test switch. This should prove that the outlet is energized and will trip off to protect against a
ground fault. Be sure to reset the ‘GFCI’ by pressing its reset switch.
6. Lift the float to prove that the pump will start when required. (Step 8 below will test submersible pumps with enclosed floats).
7. Put the necessary pail of water in the sump to prove that any check valve present will permit effluent to flow.
8. Observe that the plumbing can carry the effluent safely out of the residence.
MATERIAL REQUIRED FOR A SUBMERSIBLE SUMP PUMP APPLICATION
o Desired length of 1 1/2” or 1 1/4” of ABS/DWV pipe to link up the pump to the drain line.
o 1 only 1 1/4” check valve (350353) (Note that this 1 1/4” check valve may also be use with a 1 1/2” pipe).
o Sump pit or 1 only sump basin.
o 1 1/4”-1 1/2” stainless steel clamps (750886).
o ABS cement.
Tools
Screwdrivers, hacksaw to cut pipe, knife to assist in pipe cutting, round file to smooth pipe
ends, pipe wrench, adjustable wrench to tighten fittings.
A
B
C
D
NOTICE
This unit is not designed for applications involving
salt water or brine. Use with salt water or brine will
void warranty.
