S y S t E M f E At U R E S
pNd-K3 pORtABLE NAvIgAtION SyStEM
CRAdLE WIth CIgAREttE LIghtER ChARgER
pOWER BUttON
press and hold for 2
seconds to turn the
device on or off
Sd/MMC CARd SLOt
for music playback
(Sd card not included )
ExtERNAL
gpS/ANtENNA
CONNECtOR
RESEt BUttON
press and hold for 2 seconds
CRAdLE CONNECtOR
MINI USB
CONNECtOR
MUtE WIRE
for Installation
with Stereo
head Unit
AMpS/NEC MOUNtINg hOLES (x 4)
Use metric M4 8MM Machine Screw
ExtERNAL MICROphONE
INpUt/OUtpUt
CRAdLE EjECt BUttON
CRAdLE CONNECtOR SLOt
hEAdphONE jACK
(headphone not included)
SpEAKERS
SCREEN
vOLUME dOWN BUttON
vOLUME Up BUttON
pOWER CORd
AUdIO
OUtpUt
