Installation Instructions 25-2000
5
Re-install stock bump pad bolt into frame.
17.
Place flag nut into the top of the frame for the front hole, and lower
down until aligned with the bolt hole.
18.
Frame is cleared and ready for installation.
13.
Insert the cross member between the frame and the bed.
14.
Install the rear bump bracket onto frame and bolt to cross member.
15.
Install cross-member hardware and hand tighten nuts.
16.
Install the bolt and lightly tighten
19.
Insert flag nut into frame towards front of vehicle for second hole. Align
with the bolt hole and screw in bolt.
20.
