ReadyLift
®
(Part# 69-5010) Installation Instructions
2000-2007 Toyota Sequoia 2WD/4WD
Please read instructions thoroughly and completely before beginning installation.
Check www.Readylift.com for any updated installation instruction.
Installation by a trained mechanic is recommended.
Bill of Materials
Remove the three upper strut mounting nuts. Remove
the strut from the vehicle. Install the Readylift strut ex-
tension using the OEM nuts.
Position truck on a flat surface and lift vehicle by the frame so that the front wheels are off the ground.
Use a minimum 3 ton jack stands and place under frame for safety or a (2) two post lift if available.
Make sure that the emergency brake is on and the rear wheels are blocked to prevent a rollout.
QTY
2
6
1
1
2
2
4
2
Description
Strut Extension 2.5” Lift - Front
M10-1.25 Serrated Flange Nut - Front
Differential Drop Kit - Front
Skid Plate Spacer Kit - Front
Coil Spacer 1.5” Lift - Rear
M14-2.0 35mm Hex Head Bolt Class 10.9
M14Flat Washer
M14-2.0 Nyloc Nut
Unbolt the sway bar end link. Remove the four lower ball
joint bolts. Loosen the lower control arm frame bolts.
Remove the lower strut mounting bolt.
Re-install the strut into its stock location using the nuts
provided. Use a floor jack to raise the lower A-arm in
order to re-install the lower ball joint bolts.
1.
3.
2.
Repeat steps 1 through 3 on the Passenger
Side of the vehicle. Then re-install the sway
bar nuts on both sides after the lower ball
joints have been re-attached. Follow each
step closely, making sure to double
check the torque on all fasteners.
4.
