CT5/CT10 Instruction Manual for Power Supplies
CT5/CT10 Bedienungsanleitung für Stromversorgung

Technical Data

1)

Technische

Daten

1)

CT5.121

)

CT5.241

CT10.241

CT10.481

Output Voltage

Ausgangsspannung

nom.

DC 12-15V

DC 24-28V

DC 24-28V

DC 48-56V

Factory Setting

6)

Werkseinstellung

6)

“Single-Use”, typ.

12.0V

24.1V

24.1V

48.0V

Output Current

Ausgangsstrom

continuous

8A at 12V, 6.4A at 15V 5A at 24V, 4.3A at 28V 10A at 24V, 8.6A at 28V 5A at 48V, 4.3A at 56V

PowerBoost

2)

- 6A at 24V, 5.2A at 28V 12A at 24V, 10.3A at 28V 6A at 48V, 5.2A at 56V

Output Power

Ausgangsleistung

continuous

96W

120W 240W

240W

PowerBoost

2)

-

144W 288W

288W

Output Ripple & Noise Voltage

3)

Ausgangswelligkeit

3)

max.

100mVpp

50mVpp 50mVpp

100mVpp

AC Input Voltage

AC Eingangsspannung

nom. 2AC 380-480V

-15/+20%

2AC 380-480V

-15/+20%

3AC

380-480V

-15/+20%

3AC 380-480V

-15/+20%

Input Frequency

Eingangsfrequenz

nom.

50-60Hz

50-60Hz 50-60Hz

50-60Hz

AC Input Current per Phase

6)

AC Eingangsstrom pro Phase

6)

typ.

0.64A / 0.56A

0.75A / 0.68A

0.7A / 0.6A

0.7A / 0.6A

Power Factor

6)

Leistungsfaktor

6)

typ.

0.44 / 0.42

0.45 / 0.43

0.53 / 0.52

0.53 / 0.52

Allowed Voltage Phase to Earth

Erlaubte Spannung Phase zu Erde

IEC 60664-1, max.

576Vac

576Vac

576Vac

576Vac

PFC-Norm EN 61000-3-2

PFC-Norm EN 61000-3-2

-

Yes / Ja

Yes / Ja

Yes / Ja

Yes / Ja

DC Input Voltage

DC Eingangsspannung

nom.

-

- -

-

Input Inrush Current

4)

Einschaltspitzenstrom

4)

typ.

4A

4A 4A

4A

Hold-up Time

6)

Pufferzeit

6)

typ.

33ms / 58ms

27ms / 48ms

34 / 54ms

34 / 54ms

Efficiency

6)

Wirkungsgrad

6)

typ.

85.4% / 85.8%

90.4% / 90.0%

92.8% / 92.9%

92.8% / 92.9%

Power Losses

6)

Verlustleistung

6)

typ.

16.4W / 15.9W

12.7W / 13.3W

18.6W / 18.6W

18.6W / 18.6W

Operational Temperature Range Betriebstemperaturbereich

nom.

-25°C - +70°C

-25°C - +70°C

-25°C - +70°C

-25°C - +70°C

Output Derating

Leistungsrücknahme

60°C to 70°C

2.5W/°C

3W/°C

6W/°C

6W/°C

Storage Temperature Range

Lagertemperaturbereich

nom.

-40°C - +85°C

-40°C - +85°C

-40°C - +85°C

-40°C - +85°C

Humidity

8)

Feuchte

8)

,

IEC 60068-2-30

5 - 95% r.H.

5 - 95% r.H.

5 - 95% r.H.

5 - 95% r.H.

Vibration Schwingen

IEC 60068-2-6

2g

2g

2g

2g

Shock Schocken IEC 60068-2-27

30g 6ms, 20g 11ms

30g 6ms, 20g 11ms

30g 6ms, 20g 11ms

30g 6ms, 20g 11ms

Degree of Pollution (not conductive) Verschmutzungsgrad

(nicht leitend)

EN 50178 / 62103

2

2

2

2

Degree of Protection

Schutzart

EN 60529

IP20

IP20

IP20

IP20

Class of Protection

Schutzklasse

IEC 61140

I

9)

I

9)

I

9)

I

9)

Over-temperature Protection

10)

Übertemperaturschutz

10)

OTP

Yes / Ja

Yes / Ja

Yes / Ja

Yes / Ja

Output Over-voltage Protection

10)

Überspannungsschutz

Ausgang

10)

OVP, max.

20Vdc

32Vdc

32Vdc

60Vdc

Return Voltages Resistance

12)

Rückspeisefestigkeit

12)

max.

25Vdc

35Vdc 35Vdc

63Vdc

Leakage Current

11)

TN/TT-mains PE-

Ableitstrom

11)

TN/TT- Netze

max.

0.18mA / 0.25mA

0.18mA / 0.25mA

0.22mA / 0.31mA

0.22mA / 0.31mA

IT-mains

IT- Netze

max.

0.6mA / 0.86mA

0.6mA / 0.86mA

0.61mA / 0.88mA

0.61mA / 0.88mA

Parallel Use

13)

Parallelschaltbar

13)

-

Yes / Ja

Yes / Ja

Yes / Ja

Yes / Ja

Serial Use

5)

Serienschaltbar

5)

-

Yes / Ja

Yes / Ja

Yes / Ja

Yes / Ja

Dimensions

7)

(WxHxD) Abmessungen

7)

(BxHxT)

nom.

40x124x117mm

40x124x117mm 62x124x117mm

62x124x117mm

Weight Gewicht

max.

500g; 1.1lb

500g; 1.1lb

750g; 1.65lb

750g; 1.65lb

Approvals Zulassungen

-

Ж 14)

Ж 14)

Ж 14)

Ж 14)

Limited Warranty

Gewährleistung

Years / Jahre

3

3

3

3

1) All parameters are specified at 3x400Vac (CT10) or 2x400Vac (CT5) input voltage, symmetrical

phase voltages, nominal (continuous) output current, Single-Use” mode, 25°C ambient and after
a 5 minutes run-in time unless otherwise noted.

2) The PowerBoost is continuously allowed up to an ambient of 45°C. Above that temperature,

do not use the PowerBoost longer than 1 minute every 10 minutes.

3) 50-Ohm measurement, bandwidth 20MHz
4) Peak value, the input inrush current electronically limited and is temperature independent.
5) Use only power supplies of the same type. The total output voltage should not exceed 150Vdc.
6) At 400Vac, 50Hz / 480Vac, 60Hz, nominal (continuous) load
7) Depth without DIN-rail
8) Do not energize while condensation is present.
9) PE connection required (Ground)
10) Output shut-down with automatic restart attempts.
11) PE Leakage current at 3x440Vac, 50Hz / 3x528Vac, 60Hz
12) Loads such as decelerating motors and inductors can feed voltage back to the output of the

power supply. The figure represents the maximum allowed feed back voltage

13) Parallel use for a higher output power is allowed up to an ambient temperature of +45°C. A fuse

(or diode) on the output is required if more than three units are paralleled. Set jumper on the front
to “Parallel Use” (CT10 only).

14) See datasheet or markings on the unit.

1) Alle Werte gelten bei 3x400Vac (CT10) oder 2x400Vac (CT5), symmetrische Phasenspannung,

Nennausgangsstrom (continuous load), „Single-Use“ Einstellung, 25°C Umgebung und nach
einer Aufwärmzeit von 5 Minuten, wenn nichts anderes angegeben ist.

2) Der PowerBoost kann bis 45°C dauerhaft entnommen werden. Über 45°C darf der PowerBoost

nicht länger als 1 Minute alle 10 Minuten wiederholt werden.

3) 50-Ohm Messung, Bandbreite 20MHz
4) Spitzenwert, der Einschaltstromstoß ist elektronisch begrenzt und temperaturunabhängig.
5) Nur gleiche Geräte bis zu einer Gesamtspannung von 150Vdc.
6) Bei 400Vac, 50Hz / 480Vac, 60Hz, Nominallast (continuous load)
7) Tiefe ohne DIN-Schiene
8) Nicht betreiben, solange das Gerät Kondensation aufweist.
9) PE Verbindung erforderlich.
10) Ausgang schaltet ab und macht regelmäßig automatische Startversuche.
11) Erd-Ableitstrom bei 3x440Vac, 50Hz / 3x528Vac, 60Hz
12) Bremsende Motoren oder Induktivitäten können Spannung zum Ausgang des Netzteils

rückspeisen. Der Wert gibt die max. zulässige Rückspeisespannung an.

13) Parallelschaltung zur Leistungserhöhung ist bis zu einer Umgebungstemperatur von +45°C

erlaubt. Bei mehr als drei Geräten eine Sicherung oder Diode zur Entkopplung verwenden.
Steckbrücke an der Front des Gerätes auf „Parallel Use“ umstellen (nur CT10).

14) Siehe Datenblatt oder Prüfzeichen auf dem Gerät.




Installation

Use DIN-rails according to EN 60715 or EN 50022 with a height of 7.5 or 15mm. Mounting
orientation must be input terminals on the bottom. For other orientations see data sheet. Do not
obstruct air flow as the unit is convection cooled. Ventilation grid must be kept free of any
obstructions. The following installation clearances must be kept when power supplies are
permanently fully loaded:

Left / right: 5mm (or 15mm in case the adjacent device is a heat source)

40mm on top, 20mm on the bottom of the unit.

Use in hazardous location areas
Units which are marked with "Class I Div 2" are suitable for use in Class I Division 2 Groups A, B,
C, D locations.
WARNING EXPLOSION HAZARDS!
Substitution of components may impair suitability for this environment. Do not disconnect the unit
or operate the voltage adjustment or S/P jumper unless power has been switched off or the area
is known to be non-hazardous. A suitable enclosure must be provided for the end product which
has a minimum protection of IP54 and fulfils the requirements of the EN 60079-15:2010.

Installation

Geeignet für DIN-Schienen entsprechend EN 60715 oder EN 50022 mit einer Höhe von 7,5 oder
15mm. Der Einbau hat so zu erfolgen, dass sich die Anschlussklemmen für den Eingang unten
befinden. Für andere Einbaulagen siehe Datenblatt. Luftzirkulation nicht behindern! Das Gerät ist für
Konvektionskühlung ausgelegt. Es ist für ungehinderte Luftzirkulation zu sorgen. Folgende
Einbauabstände sind bei dauerhafter Volllast einzuhalten:

Links / rechts: 5mm (oder 15mm bei benachbarten Wärmequellen)

Oben: 40mm, unten 20mm vom Gerät.

Betrieb in explosionsgefährdeter Umgebung
Geräte, die mit "Class I Div 2" gekennzeichnet sind, sind für den Einsatz in Klasse I Division 2
Gruppen A,B,C,D Umgebung geeignet.
ACHTUNG EXPLOSIONSGEFAHR!
Veränderungen am Gerät können die Tauglichkeit für diese Umgebung beeinträchtigen. Anschlüsse
nicht abklemmen, S/P-Jumper und Spannungseinstellung nicht verändern, solange Spannung
anliegt oder die Umgebung als explosionsgefährlich gilt. Das Gerät muss mindestens in ein IP54
Gehäuse, welches den Anforderungen der EN 60079-15:2010 entspricht, eingebaut werden.

Input Fuses

The internal input fuse is not user accessible. The units are tested and approved for branch
circuits up to 32A. An external protection is only required if the supplying branch has an ampacity
greater than this, however, in some countries local regulations might apply. Check local codes
and requirements. If external fuses are necessary or utilized, minimum requirements need to be
considered to avoid nuisance tripping of the circuit breaker. A minimum value of 6A B- or 3A C-
Characteristic breaker should be used.

Sicherungen am Eingang

Die Geräte besitzen eingebaute Eingangssicherungen, die nicht anwenderzugänglich sind. Die
Geräte sind geprüft und zugelassen zum Anschluss an Stromkreisen bis max.32A. Ein zusätzlicher
externer Schutz ist nur erforderlich, wenn der Speisestromkreis mit einem höheren Wert abgesichert
ist oder nationale Richtlinien es vorschreiben. Falls externe Schutzelemente verwendet werden,
sollen diese nicht kleiner als 6A B- oder 3A C-Charakteristik sein, um ein fehlerhaftes Auslösen zu
vermeiden.
