Alpha Plus International AI-YB9021B - Manual (Page 9)

© Alpha Plus International LTD. 2009
Technical Parameters
No. Item Specification
1.
AC input: Rated Input Voltage (50-60Hz)
DC input: Rated Input Voltage
AC 100V-240V / 1.8A
DC 12V / 10A
2.
AC Input Rated Current
DC: Input Rated Current
1.8A
10A
AC: Input Power
DC: Input Power
110VA
100VA
3.
Output power (max) 90W
AC: Efficiency
DC: Efficiency
> 85% (TYP)
> 87% (TYP)
5.
Output voltage: DC 12V/15V/16V/18V/19V/20V/22V/24V
(-0.6/+0.6V@rating load)
Output Current: DC 12V/15V/16V/18V/19V/20V 4.5A max
22V/24V 3.75A max
USB port
DC 12V-24V
4.5A maximum
DC 5V 1A maximum
