Alpha Plus International AI-YB9021B - Manual (Page 5)

© Alpha Plus International LTD. 2009
Compatibility Chart: Note/Netbook Tips:
Tip A: 6.5mm x 4.5mm with 1.5mm pin
FUJITSU: 16V/3.36A, 16V/3.75A, 19V/3.16A, 19V/3.69A, 19V/4.22A SONY: 16V/3.42A,
16V/3.75A, 16V/4A, 19.5V/2.7A, 19.5V/3A, 19.5V/4.1A, 19.5V/4.7A, etc.
Tip B: 6.3mm x 3.0mm
TOSHIBA: 15V/3A, 15V/4A, 15V/5A, 15V/6A; NEC:15V/6A, etc.
Tip C: 5.5mm x 2.5mm
IBM: 19V/4.2A; DELL: 19V/3.16A, 19V/3.42A; DELTA: 19V/2.64A;
COMPAQ/HP: 18.5V/4.9A, 19V/4.9A; TOSHIBA: 19V/3.16A, 19V/3.42A, 19V/4.74A;
ASUS: 19V/4.74A. LS: 20V/3.25A; LITEON: 19V/3.16A, 19V/3.42A, 19V/3.95A, 19V/4.74A;
NEC: 19V/2.64A, 19V/3.16A; GATEWAY:19V/3.16A, 19V/3.42A, 19V/3.68A, 19V/4.74A;
IBM: 16V/2.2A, 16V/3.36A, 16V/3.5A, 16V/4.5A, ADVENT, MSI, MSI WINDBOOKS, PACKARD BELL
etc.
Tip D: 5.5mm x 2.1mm
ACER:19V/3.16A, 19V/3.42A, 19V/4.74A; LITEON: 19V/3.16A,19V/3.42A; NEC:19V/3.16A, etc.
