Alpha Plus International AI-YB9021B - Manual (Page 6)

© Alpha Plus International LTD. 2009
Tip E: 5.5mm x 2.1mm (clip)
TOSHIBA: 19V/3.95A; ACER: 19V/3.42A; DELTA: 20V/3.5A, etc.
Compatibility Chart: Note/Netbook Tips:
Tip F: 4.8mm x 1.7mm (clip)
ASUS:19.0V/2.46A, 19V/2.64A ; BENQ: 18.5V/3.5A;
LG: 19V/4.74A（LG A1 F1 LM60 LS55 LW40 M1 M6 S1 TX W2 W4 ）
HP (PRESARIO); NEC: 19V/2.64A; Delta:19V 2.64A
HP/Compaq: 18.5V/2.7A; 18.5V/3.5A; 18.5V/3.8A, 18.5V/1.1A, 18.5V/4.9A, 19V/4.74A, etc.
Tip G: 4.0mm x 1.7mm (clip)
Compaq 18.5V/Dt4, MEDION etc .
Tip H: 5.5mm x 3.0mm (with 1.0mm pin)
SAMSUNG 19V/3.16A, 19V/3.75A, 19V/4.22A, 19V/4.74A, NC10 etc
Tip I: 7.4mm x 5.0mm (with 0.65mm pin)
DELL: 19.5V/3.34A, 19.5V/4.62A, 19.5V/6.7A, 19.5V 7.7A; HP：18.5V/3.5A, etc.
Tip O: 7.7mm x 7.0mm (with 2.0mm pin)
Apple G4: 24V (not compatible with MagSafe)
