American Dryer Corp. ADH-120 User Manual
Page 13
9
2. Dryer Rear View
Illus. No.
Description
1
Basket (drive) Motor Assembly
2
Impellor (fan/blower) Assembly
3
Idler Bearing Mount Assembly
4
Basket (tumbler) Bearing Mount Assembly
5*
Electric Service Relay Box
6
Filter Housing
7
Steam Coil
8
Filter Access Panel
*
Electric service connections are made in this box for steam only.
