GX1660 User Manual 70-0057A-A
Allied Vision Technologies (Canada) Inc. 25
Video Iris Connection
VIDEO SIGNAL
LENS GROUND
12V POWER
POWER GROUND
VIDEO
AUTO-IRIS
LENS
1
2
3
4
JEITA CONNECTOR
1
2
3
4
LENS POWER
1
2
3
4
5
6
7
8
9
10
11 12
HIROSE HR10A-10P-12S
1
2
3
4
5
6
7
8
9
10
11
12
12V_POWER
POWER GROUND
HIROSE 3240-8P-C(50)
1
2
3
4
5
6
7
8
