10
ITEM QTY DE SCRIPTION ERC-3615 ERC-3623 ERC-3625 ERC-5230 ERC-5245 ERC-5255
2 2 Cover – Bearing NA NA NA 181778 181778 181778
5 2 Bearing – Wheel w/collar 181715 181715 181715 181715 181715 181715
8 1 Dia. Seal Assembly 181629 181629 181629 181725 181725 181725
9 1 Dia. Seal Assembly 181630 181630 181630 181724 181724 181724
10 1 Dia. Seal Assembly 181627 181627 181627 181724 181724 181724
11 1 Dia. Seal Assembly 181628 181628 181628 181725 181725 181725
12 1 Dia. Seal I nsert Set (8/set) 181653 181653 181653 181766 181766 181766
13 1 Shaft – Wheel Drive 183637 183637 183637 181779 181779 181779
14 8 Segment, Desiccant –S ingle 181647 181651 183635 181752 181745 18520004
14 8 Segment, Sensible-Single 181645 181649 183636 181753 181747 18520005
14 1 Segment Set-Desiccant 181646 181650 183633 181750 181744 18520002
14 1 Segment Set-Sensible 181644 181648 183634 181751 181746 18520003
15 1 Clip – Segment Retaining 181763 181763 181763 181763 181763 181763
16 1 Belt, Wheel Drive 181643 181643 181643 181770 181770 181770
17 1 Pulley, Wheel Drive 181760 181760 181760 181760 181760 181760
18 1 S eal-W heel Perimeter 181652 181652 181652 181758 181758 181758
20 2 Seal – Rim 181622 181622 181622 NA NA NA
20 4 Seal – Rim NA NA NA 181735 181735 181735
22 1 Motor – W heel Drive, 230V w NEMA Plug 181759 181759 181759 181756 181756 181756
22 1 Motor – Wheel Drive, 230V w AMP Conn. 181761 181761 181761 181762 181762 181762
ILLUSTRATED PARTS BREAKDOWN
FOR
36 & 52 SERIES ENERGY RECOVERY CASSETTES
ITEM QTY DE SCRIPTION SERIE S 36 SERIE S 52
1 4 S crew, 10-32 x 3/8” Slotted Hex Washer, Type FZ NA X
3 4 Nut, M6-1 Self Locking Hex X X
4 4 Washer (shim), 0.500 OD x 0.265 ID x 0.031 Thick X X
6 4 Screw, 10-32 x 1/2” Sems Lock washer, Hex Head S lot ted X
6 8 S crew, M6 – 1-6G x 12mm Hex Cup X
7 8 Screw, M5 x .o8G Hex Washer Machine X X
19 2 Screw, Tek 10-16 x 1/2” Hex W asher X
19 4 Screw, Tek 10-16 x 1/2” Hex W asher X
21 4 Lock Nut, 8-32 Keps X X
HARDWARE ITEMS
