35

SEPARATED COMBUSTION TUBULAR BLOWER

UNIT NUMBER DESCRIPTION

DIGIT

T

X

X

X

1

2

3

4

5

6

7

8

9

10 11 12 13 14

+

ITEM

PREFIX

UT

CA

FT FM GT AL GC SV MT MS

AS

(Internal Use Only)

Digit #1, 2 - Unit Type [UT]

Digit #12 - Motor Type [MT]

SC - Separated Combustion Tubular Blower

1 - Open Drip Proof (Standard)

2 - Totally Enclosed

Digit #3, 4, 5 - Capacity [CA]

3 - Premium Efficiency, Open Drip Proof

100 - 100,000 BTU/HR

4 - Premium Efficiency, Totally Enclosed

125 - 125,000 BTU/HR

150 - 150,000 BTU/HR

Digit #13 - Blower Motor Sizes [MS]**

175 - 175,000 BTU/HR

A - 1/4 HP w/Contactor

P - 1/2 HP w/Magnetic Starter

200 - 200,000 BTU/HR

C - 1/2 HP w/Contactor

R - 3/4 HP w/Magnetic Starter

250 - 250,000 BTU/HR

D - 3/4 HP w/Contactor

S - 1 HP w/Magnetic Starter

300 - 300,000 BTU/HR

F - 1 HP w/Contactor

T - 1-1/2 HP w/Magnetic Starter

350 - 350,000 BTU/HR

G - 1-1/2 HP w/Contactor

U - 2 HP w/Magnetic Starter

400 - 400,000 BTU/HR

H - 2 HP w/Contactor

W - 1/4 HP w/Magnetic Starter

J - 1/4 HP

0 - None/Not Applicable

Digit #6 - Furnace Type [FT]

L - 1/2 HP

A - Right Side Access

**Notes: 1. All 3-phase units [SV = 4, 5, 6, 7] include a contactor as standard.

2. All single phase units [SV = 1, 2, 3] include a contactor for units equipped with

Digit #7 - Heat Exchanger Construction Material [FM]

3/4 HP. motor or higher [MS =D, F, G, H]

1 - Standard (Aluminized) Steel

3. [MS] options J, L only available with [SV] option 1 (115/1/60).

2 - 409 Stainless Steel

Digit #14 - Accessories [AS]

Digit #8 - Gas Type [GT]

N - Natural Gas

FACTORY INSTALLED

P - Propane Gas (LP)

M8 - Discharge Duct Flange

S3 - 409 Stainless Steel Flue Collector

P4 - Terminal Block Wiring

S5 - 304L Stainless Steel Burners

Digit #9 - Altitude [AL]

P6 - Summer/Winter Switch

S - 0–4,999 ft.

† FIELD INSTALLED (AS-____ )

T - 5,000–11,999 ft.

All Field Installed Accessories are to be entered as a separate line item using

Note: Installations over 2,000 ft. require gas input deration in the field.

catalog number which utilizes “AS” as a prefi x. i.e: A7 becomes AS-A7.

Refer to unit installation instructions.

A7 - Pressure Regulator 1/2-2 psi

M2-2 - Vent Caps (5") (Unit Capacity 100-250)

Digit #10 - Direct Spark Gas Control [GC]

M2-3 - Vent Caps (6") (Unit Capacity 300-400)

1 - Single Stage

F1 - 1-Stage T675A Ductstat

2 - Two Stage

F2 - 2-Stage T678A Ductstat

P5 - 24V SPST Relay-Specify Purpose

3 - Electronic Modulation w/Room Sensing

4 - Electronic Modulation w/Duct Sensing

G1 - 1-Stage T87K Mercury Free Thermostat

X2 - 30 Degree Downturn Nozzle

5 - Electronic Modulation w/Duct Sensing & Room Override Stat

w/Subbase Kit

X3 - 60 Degree Downturn Nozzle

6 - Electronic Modulation w/External 4-20 mA Input

G2 - 1-Stage T87K Mercury Free Thermostat

X4 - 90 Degree Downturn Nozzle

7 - Electronic Modulation w/External 0-10 VDC Input

w/TG511A Guard Kit

X5 - Vertical Louver Kit

G3 - 1-Stage T834N Mercury Free

Digit #11 - Supply Voltage [SV]

Thermostat/Fan Switch

X7-H5 - Horiz. Combustion Air Inlet Kit, 5 inch

1 - 115/1/60

5 - 230/3/60

G5 - 2-Stage TH5220D Mercury Free

(Unit Capacity 100-250)

2 - 208/1/60 6 - 460/3/60

Thermostat w/Subbase

X7-H6 - Horiz. Combustion Air Inlet Kit, 6 inch

3 - 230/1/60 7 - 575/3/60

G6 - Locking Thermostat Cover

(Unit Capacity 300-400)

4 - 208/3/60 Z - Special

G8 - 1-Stage T6169C Line Voltage Stat

X7-V5 - Vert. Combustion Air Inlet Kit, 5 inch

Note: Supply Voltages [SV] 2-7 include factory mounted step down transformer.

w/Subbase

(Unit Capacity 100-250)

G9 - 1-Stage T822K Mercury Free

X7-V6 - Vert. Combustion Air Inlet Kit, 6 inch

Thermostat

(Unit Capacity 300-400)
