Yokogawa JUXTA FM1V Isolator (mV DC Input, Free Range Type) User Manual
User's manual, Checking product specifications and package, General

User's
Manual
Thank you for purchasing the JUXTA Signal Conditioner.
Please read through this manual before use for correct handling.
Network Solutions Business Division
2-9-32, Naka-cho Musashino-shi, Tokyo 180-8750 Japan
Phone: +81-422-52-7179 Facsimile: +81-422-52-6619
IM 77J08M01-01E
1st Edition Jan.2008 (YK)
CAUTIONARY NOTES FOR SAFE USE OF THE
PRODUCT
This User’s Manual should be carefully read before installing and
operating
the product. Please keep this User's Manual for future reference.
The following symbol is used on the product and in this manual to
ensure safe usage.
This symbol is displayed on the product when it is
necessary to refer to the User's Manual for information
on personal and instrument safety. This symbol is
displayed in the User's Manual to indicate precautions
to avoid danger to the operator, such as an electric
shock.
The following symbols are used only in this manual.
NOTE
D r a w s a t t e n t i o n t o e s s e n t i a l i n f o r m a t i o n f o r
understanding the operations and/or functions of the
product.
CHECKING PRODUCT SPECIFICATIONS AND
PACKAGE
(1) Checking the Model and Product Specifications
Check that the model and specifications indicated on the
nameplate
attached to the main unit are as ordered.
(2) Packaged Items
Check that the package contains the following items:
FM1A or FM1V: 1
Mounting block: 2
Tag number label and Range label: 1 each
Mounting screw (M4 x 0.7): 2
User’s Manual (this manual : IM 77J08M01-01E)
GENERAL
The FM1A/FM1V is a compact, front terminal connection type
isolator that converts mV signals into isolated DC current or DC
voltage signal.
Input range setting, burnout setting, zero/span adjustment,
and I/O monitoring can be made using the optional Parameter
Setting Tool (VJ77) or Handy Terminal (JHT200).
MODEL AND SUFFIX CODES
Model
Suffix codes
Description
FM1A
- *C
/
Isolator
(mV DC Input, Free Range Type)
FM1V
Input
-1
DC potential difference signals
-100 to +150 mV, Span: 3 mV or more
Output
A
4 to 20 mA DC
FM1A
B
2 to 10 mA DC
C
1 to 5 mA DC
D
0 to 20 mA DC
E
0 to 16 mA DC
F
0 to 10 mA DC
G
0 to 1 mA DC
Z
(Custom order)
DC current signal
1
0 to 10 mV DC
FM1V
2
0 to 100 mV DC
3
0 to 1 V DC
4
0 to 10 V DC
5
0 to 5 V DC
6
1 to 5 V DC
7
-10 to +10 V DC
0
(Custom order)
DC voltage signal
Style code
*C
Style C
Burnout
/BU
Up
/BD
Down
/BN
None
Models FM1A, FM1V
Isolator
(mV DC Input, Free Range Type)
