1. Programmable Features:
Feature LtsFlash1X Lts Flash 2X Lts Flash 3X Lts Flash 4X Default
1 Run Time 5 Min. 10 Min. 15Min. 20 Min. 10 Min
2 Park Lights On Steady Flash Steady
3 Input Check Voltage Tach Tach
4 Voltage Level > 0.5V B4 Start < 0.5V B4 Start > 0.5
5 Ign. 2 Crank Off On On
6 Diagnostics Off On Off
7 Crank Time 0.8Sec 1.0 Sec 1.5 Sec 2.0 Sec 1.0
8 Gas/Diesel Gas Diesel 10 Diesel 15 Diesel 20 Gas
NOTE:
1) When selecting Diesel operation over gasoline, the only change is to the ignition 1 circuit. When Diesel is
selected, the ignition 1 circuit will power up 10 seconds before the start circuit. The intent of this feature is to
allow the glow plug warming required by some diesel engines. If your vehicle is a instant start diesel, it is
not necessary to activate this feature.
When selecting Diesel mode, be certain that the intended vehicle has a true tach reference and be certain
to connect the tach input wire.
NOTE:
2) The Crank Time Selection, is considering the time it takes from when the unit reaches the preset RPM to
when the Starter Motor drops out. This feature allows fine adjustments when you note a slight overcrank. If
after programming tach, the unit seems to hold the starter engaged slightly longer than necessary, select
this feature to pole 3 X. If the unit starts and the starter drops out properly, (NO OVERCRANK) no change is
necessary.
To program these selectable features:
1. Start with the ignition switch in the "OFF" position and the programming switch in the "ON" position.
2. Turn the ignition key to the ON position.
3. Within 5 Seconds begin to toggle the control/program switch OFF - ON - OFF - ON - OFF then ON.
3a Parking Lights Turn On.
4. Within 5 Seconds, Turn the ignition key OFF, then ON.
4a Parking Lights Turn Off.
5. Within 5 Seconds begin to toggle the control/ program switch OFF - ON - OFF then ON.
5a Parking Lights Turn On For 1 Seconds Then Off Indicating Program Mode Entered.
6. Within 5 seconds of the lights turning off, begin to move the control/program switch off then on to sequentially
move through the programmable features.
Example: Press and release the brake to toggle between 5, 10, 15 or 20 minutes run time, or, move the switch on then
off to advance to feature 2, the lights will flash twice indicating feature 2, parking lights on or steady, is selected. Press
and release the brake to toggle between on or steady. Continue to move the switch on then off until you've moved
through the programmable features setting each with the brake pedal as described.
2. Programming Tach Rate:
NOTE: All applications require that tach be programmed.
The unit will not operate unless tach is programmed. If an attempt is made to start the vehicle via the remote start
without first programming tach, the unit will flash the parking lights 7 times indicating tach has not been learned and
stored. If the tach rate is not properly programmed to the specific vehicle, the unit may not realize that the vehicle is
running, and in certain instances reengage the starter motor.
