Yokogawa SC25F - Manual (Page 16)

IM 12B6J3-04E-E
16
60
PG 13,5
3/4"NPT
44
PG 13,5
M25 x 1.5
Ø13.5
PG13.5
10
Fig 11: Dimensions adapters
K1500DV, K1520JN, K1520JP
Fig 12: Dimensions adapters
K1523JA, K1523JC
Fig 13: Dimensions adapters
K1523JB, K1523JD
Fig 10: Dimensions SC25F Sensor
4 DIMENSIONS
Dimensions in mm
Adapter
PG13.5 to 3/4”NPT
K1523JB (PPO)
K1523JD (SS)
Seal, e.g. with
Teflon tape
3/4”NPT
1/4”NPT
Adapter
PG13.5 to SC-fitting
K1523JA (PPO)
K1523JC (SS)
Adapter
PG13.5 to 3/4”NPT
K1523JB (PPO)
K1523JD (SS)
Adapter
M25 x 1,5 - PG13.5
K1520JN (PVC)
K1520JP (SS)
K1500DV (PVDF)
1/4”NPT
Flow fitting SS
K1598AC
M9-Connector
Wrench 19
PG13.5
Slide ring (Ryton)
O-ring
ш
12
ш
10.7 -0.7
<25
120 / 225 ±2.0
223 ±2.0 / 328 ±2.0
Adapter
PG13.5 to SC-fitting
K1523JA (PPO)
K1523JC (SS)
FF40-S22
FS40-S22
O-ring 29.74 x 3.53
Fitting
Plastic FS40
Plastic FF40
3/4”NPT
Slide ring (Ryton)
O-ring
Slide ring (Ryton)
O-ring
Slide ring (Ryton)
O-ring
Slide ring (Ryton)
O-ring
When mounting in
FD20
FF20
FS20
use O-ring 11 x 3
Slide ring (Ryton)
O-ring
Sensor
Holder
PG13.5
PG13.5
M25 x 1.5
44
Adapter PG13.5
M25 x 1,5
K1500DV (PVDF)
K1520JM (PVC)
K1520JP (SS)
PG13.5
60
PG13.5
10
ø
13.5
Adapter PG13.5 to SC-fitting
K1523JA (PPO)
K1523JC (SS)
Sensor Holder
PG13.5
K1525AB
<21
