13
Critical Application
Thread
Locker
Torque Range
(ft-lbs)
Wheel motor bolts (Securing motor to support) Loctite 2760 40-50
Clutch to engine shaft Loctite 2760 50-55
Wheel hub to wheel motor N/A 175-225
Wheel lug nuts N/A 80-90
Split Hub (Spindle & Drive) (Gr 8) N/A 13-17
Torque Specifications
Width, deflector down 61"
Width, deflector up 49"
Length 59"
Height 47"
Weight 820 lbs
Width, deflector down 65"
Width, deflector up 53"
Length 60"
Height 47"
Weight 845 lbs
Width, deflector down 74"
Width, deflector up 62"
Length 62.5"
Height 47"
Weight 870 lbs
48" Stander
52" Stander
61" Stander
Fuel System
•
Capacity: 5.6 Gal. (L)
•
Type of Fuel: Unleaded regular gasoline, minimum 85 octane. Do not use gasoline containing
more than 10% ethanol. Do not mix oil with gasoline.
•
Fuel Filter: In line
•
Fuel shut off: On, Off located on fuel tank
Safety Interlock System
•
PTO switch must be disengaged, brake engaged and the control handles in the neutral and
locked position to start the engine.
•
Operator must have feet on the platform to engage the PTO and brake off or engine will stop.
Drive System:
•
Two Hydro Gear 12cc w/fans variable displacement piston pumps
•
Two Hydro Gear 15cu in. wheel motors
Hydro Oil System
•
Hydro Oil: fully SYNTHETIC motor oil: Mobil-1 15W-50
•
Hydro Filter: Spin-on, 25 micron, no bypass / PN 34490002
•
Total Capacity: 3 qts
•
Tank Fill Level: Fill until fluid comes from fill port.
