Rev 1/08 ©2008 ATTO Technology, Inc. Specifications subject to change without notice.
Power Behind the Storage
Technical Specification
For More Information:
www.ATTOTech.com
or to Purchase:
www.ATTOStore.com
(716) 691-1999
Technical Features
RAID Levels • JBOD, DVRAID, 0, 1, 4, 5, 6*, 10, 40, 50 and 60* plus N-way mirroring
Key Features
Hardware Specifications
Fibre Channel Interface • 4-Gigabit, auto-negotiates to 2/1 Gigabit devices
• Four Optical SFP (Small Form Factor Pluggable) Fibre Channel ports
• Full support for direct connect for F-port fabric switches
• Class 3 and Intermix ANSI Fibre Channel Specifications
• PLDA, public loop login (NL-ports) and fabric connect (N-port)
• Full-duplex transmissions
SAS/SATA Interface • Eight 3-Gb SAS/SATA ports via two four-port MiniSAS (SFF-8080) connectors
Management Interface • RJ-45 connector for Ethernet management port
• RS-232 serial header console port
Management
Setup and Monitoring • Simplified one-click setup allows for system setup in just minutes
• Built in read-only drive performance monitoring allows you to gauge
storage performance while host-based applications are in use
Local and Network Management • ExpressNAV TM storage manager browser-based user interface for remote
configuration, management and diagnostic capabilities
• Local diagnostics supported via CLI, Telnet and FTP
• Command line and menu-based ASCII text management access via the
Ethernet management port and ExpressNAV
Environmental & Physical Specifications
Dimensions • 1.69” (1U) H x 17.31” W x 9.9” L
Operating Environment • Temperature: 5 - 40° C ● Humidity: 10 - 90% non-condensing
Storage Environment • Temperature: -40 - 70° C ● Humidity: 5 - 95% non-condensing
Power • Input: 100-240 VAC, 2.5A, 47-63 Hz
Fixed Airflow • 11 CFM
• Ambient air not to exceed 40° C
RoHS Compliant • Yes
Ordering Information
Model Number FSSC-7500-D00
FastStream™ SC 7500
Storage Controller
FastStream SC 7500
• Tunable RAID Rebuild Priority • Zoning LUN mapping (optional)
• Real-time Performance Metrics • One button setups for Audio, Video, IT
• Application Performance Reporting • Field Upgradeable Firmware
• Global Hot Spares • O/S Independent Operation
• Audio Latency Management • Battery Backed Event Log
• Drive Initialization and Verification • ECC Protected Memory
• Partitioning of RAID Volumes • Phone Home email Error Notification
• Port Mapping for LUN Isolation • ExpressNAV™ Storage Manager
*RAID 6 and 60 planned for Q1 2008
