ENGLISH

ENGLISH

FAUCET FUNCTIONS

MAINTENANCE & CARE

CAUTION: Maintenance

DISASSEMBLY

1. Replacement parts may be available at the store where you purchased

your faucet.

2. When replacement parts are not available, please write or call Price

Pfister Consumer Service.

3. Always turn off water and relieve pressure before working on your

faucet.

NOTE: Trim Care

Cleaning Instructions:

For all handles and decorative finishes, use only a soft damp

cloth to clean and shine. Use of polish, detergents, abrasive

cleaners, organic solvents or acid may cause damage.

Use of

other than a soft damp cloth will nullify our warranty!

Special Trim:

Trim products which contain porcelain or other similar substance

are not acceptable for public areas or commercial use. Installation

of Said Trim is at Users Risk!

1–800–PFAUCET (1–800–732–8238)

For Toll-Free Pfaucet information call

1–800–PFAUCET (1–800–732–8238)

or visit www.pricepfister.com

• Installation Support

• Care and Warranty Information

7 SPOUT BOBY INSTALLATION

Place Spout Flange (7A) over Spout Adapter (7B). Push Spout Flange (7A) by hand until

it is snug and flush to finished wall surface. Insert Spout Body (7C) onto Spout Adapter

(7B). Push Spout Body until it s properly positioned and flush to Spout Flange (7A). Be

sure that both Spout Body (7C) and Spout Flange (7A) are horizontaly aligned. From

below Spout Body (7C) tighten Screw (7D) located at the bottom of spout as shown.

8 UNIT START UP

Turn on hot and cold water supplies, and check for leaks above and below the sink.

9 FAUCET FUNCTION

COLD valve: close-counterclockwise, open-clockwise; HOT valve: close-clockwise,

open-counterclockwise.

OPEN

HOT

COLD

OPEN

FINISHED WALL
