ENGLISH
ENGLISH
MAINTENANCE & CARE
13
14
15
16
CAUTION: Maintenance
DISASSEMBLY
1.
Replacement parts may be available at the store where you purchased
your faucet.
2. When replacement parts are not available, please write or call Price Pfister
Consumer Service.
3. Always turn off water and relieve pressure before working on your
faucet.
NOTE: Trim Care
Cleaning Instructions:
For all Handles and decorative finishes, use only a soft damp cloth
to clean and shine. Use of polish, detergents, abrasive cleaners,
organic solvents or acid may cause damage. Use of other than
a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain Porcelain or other similar substance
are not acceptable for public areas or Commercial use. Installation
of Said Trim is at Users Risk!
1–800–PFAUCET (1–800–732–8238)
For Toll-Free Pfaucet information call
1–800–PFAUCET (1–800–732–8238)
or visit www.pricepfister.com
• Installation Support
• Care and Warranty Information
13 SIDE SPRAY OPERATION
The Side Spray (13A) can be pulled forward to spray water in any direction. To activate the
Side Spray, press the Toggle Button (13B) located on the back of the Side Spray (13A).
14 FLUSHING & AERATOR CLEANING
After installation is complete, remove Aerator Housing (14A). Turn Valves (14B) on
and allow both hot and cold water to run for at least one minute each. While water is
running, check for leaks. To clean the aerator, disassemble Aerator Housing (14A) by
separating the Aerator Head (14C), Basket (14D) and Washer (14E). Once parts have
been cleaned, reassemble by reversing steps.
15 HANDLE REMOVAL
Turn off water before proceeding! With valves in closed position, detach Decorative
Button (15A), unscrew Fastener (15B) and remove Handle and Hub (15C) from Valve
Stem (15D).
16 VALVE CARTRIDGE REMOVAL
Turn off water supplies and relieve pressure before working on your faucet.
Remove handles (See Step 15), unscrew Retainer Nut (16A) by turning it counter-
clockwise and lift out Cartridge Assembly (16B) and inspect. Replace parts as
necessary. Reassemble parts by reversing steps.
4
13A
13B
14A
14B
14E
14D
14C
15A
15B
15C
15D
16A
16B
