Operation
12
F232072
Figure 2
Supply Dispenser
Top Cover
Control Panel
V-Computer Keypad
Emergency
Stop Button
Door Glass
Base Frame
Inner
Front
Panel
Front View
Door
Handle
Door
Outer
Front
Panel
Door
Unlock
Button
Door Unlock
Switch
Power
Connection
AC Drive Cooling
Fan Filter
Cold Water Inlet
Hot Water Inlet
Steam
Inlet
(Optional)
Vacuum
Breaker
Vent
Base
Frame
Rear Panel
Drain Outlet
B007RE3A
Rear View
