FC3860A
Single-chip 5.8GHz DSRC modem
Integrated with RF and MCU
 NAND flash controller
 NAND flash, with ECC hardware acceleration for pages raging from 256 to 8192 bytes
 LCD module support
 SPI and 4/8/16 bit parallel interface(8080-like interface and 6800-like interface)
 PWM for back light control
 Smart card interface: ISO7816
 Support asynchronous T0 and T1 transmission protocols
 Support clock rate conversion factor F=372, with bit rate adjustment factors D=1,2,or 4
 8 character deep buffered TX and RX paths
 Direct interrupts for TX and RX FIFO level monitoring
 Hardware initiated card deactivation sequence on detection of card removal
 Software initiated card deactivation sequence on transaction complete
 USB 1.1 FS device
 Full-Speed(12MHz) support
 Support control, interrupt, bulk and isochronous transfer
 FIFOs are housed inside core for both data-out and data-in paths
 Six bidirectional endpoints + Control endpoint0
 DMA
 8 DMA channels, Each channel can support a unidirectional transfer
 16 DMA requests
 Single DMA and burst DMA request signals
 Memory-to-memory, memory-to-peripheral, peripheral-to-memory and peripheral-to-
peripheral
 Interrupt Controller
 Support for 32 vectored IRQ interrupts
 Fixed or programmable interrupt priority levels
 IRQ and FIQ generation
 Software interrupt generation
 Timers
 Four 32/16-bit down counters with free-running, periodic and on-shot modes
 Common clock with separate clock-enables for each timer gives flexible control of the
timer intervals
 Watchdog Timer
 32-bit down counter with a programmable timeout interval
 Separ ate watchdog clock with clock enable for flexible control of the timeout interval
ⓒ Copyright 2009 FCI (All Rights Reserved)
Product datasheet 4/7 - September 2010
-
