G E N E R A L E N C L O S U R E A C C E S S O R I E S
W I N D O W K I T S
F E AT U R E S - S P E C I F I C AT I O N S
W I N D O W K I T S
• Steel window kits are designed
to be used indoors on NEMA 12
enclosures
• Stainless steel window kits are
suitable for NEMA 12 and 13
enclosures in an indoor application.
These kits are easily installed by
making a cutout in the enclosure
and attaching the window and
frame in place. All necessary
hardware is included
• Kits are fully gasketed to maintain
an oil tight seal
• Frames are made from heavy steel
with a ANSI 61 gray polyester
powder finish over phosphatized
surfaces. Type 304 stainless steel
with a grained finish
CATALOG NUMBER WINDOW FRAME REQUIRED
STEEL STAINLESS STEEL H X W SIZE CUT-OUT SIZE
WA P W K 0 5 0 3 N F WA P W K 0 5 0 3 S S
5 . 0 0 x 3 . 0 0 7 . 5 0 x 5 . 5 0 6 . 6 9 x 4 . 6 9
( 1 2 7 x 7 6 ) ( 1 9 1 x 1 4 0 ) ( 1 7 0 x 1 1 9 )
WA P W K 0 9 0 5 N F WA P W K 0 9 0 5 S S
9 . 0 0 x 5 . 5 0 1 1 . 5 0 x 8 . 0 0 1 0 . 6 9 x 7 . 1 9
( 2 2 9 x 1 4 0 ) ( 2 9 2 x 2 0 3 ) ( 2 7 2 x 1 8 3 )
WA P W K 1 3 0 8 N F WA P W K 1 3 0 8 S S
1 3 . 0 0 x 8 . 0 0 1 5 . 5 0 x 1 0 . 5 0 1 4 . 6 9 x 9 . 6 9
( 3 3 0 x 2 0 3 ) ( 3 9 4 x 2 6 7 ) ( 3 7 3 x 1 7 0 )
WA P W K 1 7 0 5 N F —
1 7 . 0 0 x 5 . 5 0 1 9 . 5 0 x 8 . 0 0 1 8 . 6 9 x 7 . 1 9
( 4 3 2 x 1 4 0 ) ( 4 9 5 x 2 0 3 ) ( 4 7 5 x 1 8 3 )
WA P W K 1 7 1 1 N F WA P W K 1 7 1 1 S S
1 7 . 0 0 x 1 1 . 0 0 1 9 . 5 0 x 1 3 . 5 0 1 8 . 6 9 x 1 2 . 6 9
( 4 3 2 x 2 7 9 ) ( 4 9 5 x 3 4 3 ) ( 4 7 5 x 3 2 2 )
WA P W K 2 3 1 5 N F WA P W K 2 3 1 5 S S
2 3 . 0 0 x 1 5 . 0 0 2 5 . 5 0 x 1 7 . 5 0 2 4 . 6 9 x 1 6 . 6 9
( 5 8 4 x 3 8 1 ) ( 6 4 8 x 4 4 5 ) ( 6 2 7 x 4 2 4 )
WA P W K 2 9 1 9 N F —
2 9 . 0 0 x 1 9 . 0 0 3 1 . 5 0 x 2 1 . 5 0 3 0 . 6 9 x 2 0 . 6 9
( 7 3 7 x 4 8 3 ) ( 8 0 0 x 5 4 6 ) ( 7 8 0 x 5 2 6 )
WA P W K 3 5 2 3 N F —
3 5 . 0 0 x 2 3 . 0 0 3 7 . 5 0 x 2 5 . 5 0 3 6 . 6 9 x 2 4 . 6 9
( 8 8 9 x 5 8 4 ) ( 9 5 3 x 6 4 8 ) ( 9 3 2 x 6 2 7 )
W I N D O W K I T S
WAPWK0503NF WAPWK0503SS
Enclosure
Cut-out
Mounting
Surface
Closed-Cell
Gasketing
W + 2.50
W + 1.69
H + 2.50
H + 1.69
0.31
W
H
