J15
G E N E R A L E N C L O S U R E A C C E S S O R I E S
L O C K S • L AT C H E S
F E AT U R E S - S P E C I F I C AT I O N S
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
NEMA 1 TYPE T HANDLE
LATCH & CYLINDER LOCK KITS
• The “T” handles are intended to
be used on various NEMA 1
cabinets. Not suitable for water
tight applications
• The 3 point latch comes with han-
dle, latch, latch rods and all hard-
ware. Handles are chrome plated
• Cylinder locks are designed for
field installation in the small NIC
and large NIC enclosures. Latch is
water and dust tight. It is necessary
to drill a hole in door to receive
latch
• Latch has chrome plated finish
CATALOG
DESCRIPTION
NUMBER
WA C L J I C 1-Point c y l i n d e r k e y l o c k
WA P L K J I C P a d l o c k l o c k k i t
LOCK KITS FOR JUNCTION BOXES
CATALOG
DESCRIPTION
NUMBER
WA L 3 A S S 1-Point l a t c h k i t
3-Point l a t c h k i t
WA L 3 B S S where H =
16", 20", 24" or 30" H
3-Point l a t c h k i t
WA L 3 C S S where H =
36", 42" or 48" H
3-Point l a t c h k i t
WA L 3 D S S where H =
60" or 72" H
WAL3(A-D)SS, 316LSS, N4X PADLOCKING HANDLE
CATALOG
DESCRIPTION
NUMBER
WA L 8 1 - P o i n t “ T ” l o c k i n g h a n d l e
WA 8 1 - P o i n t “ T ” n o n l o c k i n g h a n d l e
WA L 1 2 B
1 - P o i n t k e y l o c k f o r s m a l l N 1 C
e n c l o s u r e s
WA L 1 2 A R
3 - P o i n t k e y l o c k f o r l a r g e N 1 C
e n c l o s u r e s
HANDLE LATCH & CYLINDER LOCK KITS
L AT C H K I T S F O R S I N G L E
DOOR TYPE 12 ENCLOSURES
• Designed for field installation in
standard single door Type 3R,
4 and 12 enclosures
• Latch is water tight and dust tight
• It is necessary to drill or punch one
hole in the cover to receive the latch
• Complete installation instructions
are included
L O C K K I T S F O R
J U N C T I O N B O X E S
• Designed for field installation in
standard junction boxes. Latch is
water tight and dust tight
• It is necessary to drill or punch
one hole in the cover to receive
the cylinder lock
• Complete installation instructions
included
• Designed for field installation in
standard single door JIC, BCH,
BN4CH enclosures
LATCH KITS FOR SINGLE DOOR TYPE 12
Padlock
WAL1
(A,B,C,D)
WAPLKJIC
WAL8 WA8
WAL12B WAL12AR WACLJIC
WAL4
(A,B,C,D)
WAL3
(A,B,C,D)
CATALOG
DESCRIPTION
NUMBER
WA E M K A 4 Ke y f o r C o m b o K e y / P a d h a n d l e s
WAT V P K K E Y Ke y f o r N 1 2 T V P K
WA S Q K K E Y Ke y f o r N 1 2 1 4 S Q , & N 4 1 2 S Q 3
WAT T R I K K E Y Ke y f o r N 4 1 2 T T R I K
WA L 2 K E Y Ke y f o r WA L 2 A - WA L 2 D
WA C L S N 1 2 K E Y Ke y f o r WA C L S N 1 2
KEYS FOR LATCH KITS
WAL3SS
(A,B,C,D)
Keylock
WAL2
(A,B,C,D)
CATALOG NUMBER
PADLOCK KEYLOCK DESCRIPTION
HANDLE HANDLE
WA L 1 A WA L 2 A 1-Point latch kit
WA L 3 A ‡ WA L 4 A*‡ 1-Point latch kit
WA L 1 B WA L 2 B
3-Point latch kit where
H is 16", 20", 24" or 30"
WA L 3 B ‡ WA L 4 B*‡
3-Point latch kit where
H is 16", 20", 24" or 30"
WA L 1 C WA L 2 C
3-Point latch kit where
H is 36",42", or 48"
WA L 3 C ‡ WA L 4 C*‡
3-Point latch kit where
H is 36",42", or 48"
WA L 1 D WA L 2 D
3-Point latch kit where
H is 60" or 72"
WA L 3 D ‡ WA L 4 D*‡
3-Point latch kit where
H is 60" or 72"
* C o m b o k e y / p a d l o c k i n g h a n d l e .
‡ N 4 / 4 X R a t e d h a n d l e s .
